New fuel cell cabinet under Andrew brand offers environmentally
friendly power April 14, 2008 -The CommScope family of
integrated cabinets, for years one of the top choices by North American
telecommunications carriers, is being expanded under Andrew Wireless
Solutions with new products that address the unique requirements of
wireless operators around the world.
Andrew cabinets for wireless
operators are environmentally controlled enclosures that protect equipment
at a cell site or remote installation. Andrew's full line of integrated
cabinets connect and protect radio, power, amplifier and battery
electronics while delivering industry leading acoustic and thermal
performance.
The two newest additions to the
Andrew cabinet family, introduced this month, are the EcoPower™ Cabinet
and the RBA84 Series Cabinet.
EcoPower Integrated Fuel Cell Solution is
Eco-Friendly EcoPower provides an environmentally
friendly DC backup power solution for wireless and wireline networks, with
a cabinet design that is modular and flexible to meet the most stringent
backup power needs. The cabinet's proton exchange membrane (PEM) hydrogen
fuel cells, housed in a secure, weather resistant cabinet for outdoor
deployment, offers a smaller footprint and more dense power backup than
what has been available previously from competitors.
The EcoPower cabinet, at 63 inches
high by 45 inches wide by 52 inches deep, is the most compact integrated
fuel cell system available, providing up to 16kW in a single cabinet. With
power supplied by two 8kW fuel cells, the EcoPower cabinet is cooled
without use of outside air in a sealed compartment to keep out dust,
contaminants and condensation, thereby helping to prevent deterioration of
equipment housed inside.
With its cabinet cooling and
heating system, the PEM fuel cell delivers optimum power output at ambient
temperatures that can range from -40 degrees Celsius to 46 degrees C, with
an exceptionally high degree of reliability that helps ensure
uninterrupted power during utility power failures.
"Traditional battery backup
cabinets and diesel generators take a back seat to the capabilities of the
Andrew EcoPower cabinet," said Anil Trehan, chief technology officer,
Carrier. "This cabinet provides a superior eco-friendly power supply that
offers significant operational cost savings over the life of the cabinet.
It also is ideal at addressing mandated minimum power supply requirements,
such as the US Federal Communications Commission's recent ruling that
calls for at least eight hours of power backup at cell sites."
The Andrew EcoPower fuel cell
cabinet is currently available for field trials. General availability is
scheduled for June 2008.
RBA84 Cabinet - Flexible, Durable and Aesthetically Pleasing
Design The Andrew RBA84 Series Cabinet has been
designed specifically for the needs of wireless operators and original
equipment manufacturers (OEMs). Its flexible configuration enables it to
accept radio, power and battery equipment from various OEMs, providing
operators with long-term versatility at network cell sites.
The RBA84 Series also has
configurable cooling options, ranging from air conditioning to hydrophobic
or mesh filter air cooling, for optimal thermal performance, while
minimizing cost. It also utilizes variable speed fan technology to
minimize the acoustic signature. It is constructed of rugged 1/8th inch
thick aluminum, with UL50 and GR487 Zone 4 compliance, making it durable
for outdoor usage. Its aesthetic design includes a louvered front door and
three rear access panels, blending appearance and functionality.
"The RBA84 Series strengthens our
family of integrated cabinets for wireless applications," said Julie
Nielson, vice president, Product Management and Engineering, Andrew
Wireless Solutions. "Andrew cabinets are now more accommodating to various
OEM radio and power equipment, making them more versatile and available
for quicker deployment. Andrew cabinets overall help our customers protect
their considerable investment in equipment from environmental elements."
|
|
PRIMUS's Prep Tool Kit ensures that you'll have the right equipment
for a profitable project PRIMUS Electronics' newest
packaging of products will ensure that antenna and line installation
technicians can save time and money since they'll no longer need to search
for or require overnight delivery of the equipment needed to install
grounding protection and connectors.
The new PRIMUS Prep Tool Kit,
competitively priced, includes high-quality grounding and connector tools
manufactured by Andrew Corporation. It's available in one easily ordered
part number: PREPKIT-ANDREW. The kit
Includes: Automated Cable Prep Tool, 1-5/8" Cable
(CPT-158U) Automated Cable Prep Tool, LDF6 (CPT-L6) Automated Cable
Prep Tool, 7/8" Cable (CPT-78U) Automated Cable Prep Tool, 1/4" &
1/2" (CPT-F4) Automated Cable Prep Tool, 1/2" LDF4 Cable
(CPT-L4ARC1) 1-5/8" Foam LDF7 Ground Kit Tool (GKT-158A) 1-1/4"
Foam LDF6 Ground Kit Tool (GKT-114A) 7/8" Foam LDF5 Ground Kit Tool
(GKT-78A) 1/2" Foam LDF4 Ground Kit Tool (GKT-L4A 1/2" Superflexible
Ground Kit Tool (GKT-F4A)
If you're installing CommScope
transmission lines, PRIMUS also provides a similar kit that will ensure
easy and professional installation of grounding and connectors.
For additional information, and
quick and easy ordering, visit them at www.PrimusElectronics.com or contact one of their sales representatives at:
800-435-1636. |
|
Valmont's re-designed portable base monopole
and flagpole models make market impact
Over the past decade, Valmont
Structures has been providing solutions to the industry with ballasted
monopoles and flagpoles for use on semi-permanent and permanent
cellular/PCS tower sites. Valmont has seen an increasing demand to be able to
utilize the 24'x 24' square I beam base to incorporate BTS cabinets and
other equipment up to (9) nine 36" wide cabinets .
Valmont's new
design is now available with full grating, 42" high continuous handrail,
and 36" wide step options, and the universal bolt pattern accepts a 24"or
30" diameter pole that interfaces with a step monopole or
flagpole.
Valmont's portable base poles are suitable for temporary
or semi-permanent installations or permanent sites solutions where a
conventional foundation may be impractical or helping to simplify zoning
and permitting processes for fast site deployment.
The base and
monopole can be typically erected in a single day on crushed stone or
blacktop to level surface as well as provide adequate drainage.
The
design is Rev. G ready and is in conformance with the TIA-222-G standards
to heights up to 130', depending on loading. Pre-cast concrete ballasts
are supplied as required to provide code-compliant base with full safety
factors and stress ratios in force.
For more information call Stan
Fisher at 215-244-2086 or email him at stanton.fisher@valmont.com .
|
|
ITL debuts new strobe lighting
systems Nashville, TN-based aviation obstruction
lighting component and system manufacturer ITL, LLC recently
introduced a new line of ETL-certified
medium intensity strobe lighting systems at NATE 2008, including the
ILS-2400, a white L-865 strobe light, and the ILS-3400, a dual L-865/L-864
strobe light. Both systems have been ETLtested and comply with FAA
regulations as outlined in FAA Advisory Circular
AC150/5345-43E.
Redefining ease of installation
and serviceability, the new products share the same power supply and are
designed and engineered in accordance with the exacting standards for
quality and reliability that have become synonymous with the ITL name over
the last decade. The new systems feature time-proven ITL components
throughout.
These systems expand ITL's range
of products which include L-810 and L-864 incandescent lighting fixtures,
high-performance red light controllers, wireless monitoring systems, and
aftermarket products for the obstruction lighting industry. For more
information visit www.itl-llc.com , or call an ITL sales representative at
(615) 256-6030. |
|
New enhanced stainless steel ground rods ensure that
current has a downward path to ground Harger
Lightning & Grounding recently introduced their new Stainless Steel
Enhanced Grounds Rods. The rods contain special salts that help lower soil
resistivity and are used in conjunction with ground enhancement material such as
Ultrafill. Ultrafill lowers the soil resistivity immediately around the
ground rod drastically improving its efficacy.
The New 300 Series Stainless Steel
EGR's are highly resistant to corrosion. They are also used to overcome
many of the problems caused by galvanic corrosion which can take place
between dissimilar metals buried in close proximity such as copper clad
ground grounds and guy anchors.
Some other applications for these
Stainless Steel EGR's are areas with acidic soils, airports, pipe lines,
power plants and other industrial sites. Harger has also designed the
conductor portion of the ground rod to help ensure the current has a
downward path to ground, where other chemical ground rod manufacturers
utilize a design which forces the electrical (lightning) current to go "up
hill".
Another unique feature Harger has
incorporated is an inspection cap on the top of the rod. This allows for
inspection of the electrolytic salts. Harger will provide additional salts
free of charge should the salts become depleted. Harger's Enhanced Ground
Rods are UL listed and are designed to last over 25 years. They are
available in a vertical or horizontal design.
Harger Lightning & Grounding
is a leading manufacturer of lightning protection and grounding equipment,
as well as exothermic welding materials for the communications and
electrical industries. Harger also provides design and engineering
services and specializes in offering total systems solutions for their
customers. For additional information, visit their website or contact them at:
hargersales@harger.com. |
|
DBI-SALA pioneers industry's first self retracting lifeline with tie-back
capabilities DBI-SALA, a Capital Safety brand, has
introduced the new Talon™ Tie-Back Self Retracting Lifeline that
eliminates the need for a separate anchorage connector, minimizing cost
and installation time.
This revolutionary fall protection device
offers a unique solution for providing a tie-back capability to the
recognizable self retracting lifeline. Complete with a unique hook with
5,000 pound gate strength, it is designed specifically for tie-back use
and increased durability.
Talon ™ is ideal for use in tower
climbing, maintenance and erection.
The single-leg and twin-leg 100
percent Tie-Back Talon ™ self retracting lifelines are designed to
withstand the forces that occur from tie-back use.
To gauge the
forces being exhorted on the fall protection device, the self retracting
lifeline is equipped with impact indicators on each leg of either the
single or twin leg versions.
"We are dedicated to the continuous innovation within the
construction industry," states Charley Bryant, product marketing manager
of hardgoods at Capital Safety. "We are eager to introduce this new
solution that offers a better, easier and ultimately safer alternative to
getting the job done."
Three layers of webbing in the tie-back area of the lifeline
provide more abrasion resistance for added safety. The 3.5 feet of
tie-back webbing ensures that the lifeline can be anchored around most
structures. |
|
Satellite positioning antenna alignment tool expected
to become a popular US carrier standard Although most European network operators have made the use of
SPAA05 tools as their standard, US carriers are energized by the
opportunity to finally have the ability to install their antennas with
exacting alignments that can be obtained within two minutes.
The SPAA05 range of GPS based antenna alignment tools
are specially designed to improve the nominal antenna azimuth of GSM, DCS
and UMTS Mobile cellular networks.
Two versions are available at this time. The standard
SPAA05 and the all new SPAA05-NEX. Both systems feature easy to use
antenna mounting and back-office software solutions.
The models measure, in real time,
the exact antenna bearing within two minutes after switching on the
system. When using the full software -100 count- an accuracy of 0.5
degrees RMS can be achieved.
Although a number of networks
operators have not specified their needs for such very high accuracy yet,
existing antennas on many sites show clearly that many installation
companies are not achieving the current requirements of ± 3° or ± 5° with
conventional methods like using a magnetic compass or other imprecise
methods.
Oftentimes setting the correct
antenna azimuth is a problem for many line and antenna crews who forget to
include magnetic declination or they do it backwards.
Tower steel and antennas interfere
with the operation of a magnetic compass, and carriers often find that
their coverage problems are effected by unacceptable, but unnoticeable
antenna alignment.
A simple five-step procedure on
site with the new alignment tools will measure and store the individual
antenna azimuth and other important site information. The file encryption
process secures the measurement results including time, date and position
stamping. Back-office processing takes only a few minutes per site.
For addition information on the
SPAA05 and the SPAA05-NEX, or for distributor contact information, visit:
SPAA05-NEX |
|
Comsearch's AuctionPlanner will assist bidders in contentious 700
MHz FCC sale Bidders in the January 24, 2008 US Federal
Communications Commission auction of 700 MHz spectrum can arm themselves
with a valuable advantage-the new 700 MHz AuctionPlanner™
product from Comsearch, an Andrew Corporation
company.
It should prove to be helpful in
assisting bidders with an advantage in what may prove to be one of the
most controversial wireless auctions in history. This will be one of the
last chances for many years to get new spectrum, and many operators such
as Qualcomm, AT&T and Google will be obligated to bid on it whether
they have an immediate need for it or not.
AuctionPlanner provides the
critical information that spectrum bidders need to assess the incumbent
environment both prior to and after the January 24, 2008 auction of the
700 MHz frequency band, now used for television broadcasting.
AuctionPlanner enables users to easily identify current TV stations that
operate in the band, supported by customizable maps and spreadsheets that
detail existing coverage areas, operating parameters, station
classifications and ownership information. AuctionPlanner also helps
to provide estimates of the number of sites required to achieve FCC
wireless network build-out requirements.
"Reliable, complete information is
critical to be successful in the upcoming 700 MHz spectrum auction," said
Chris Hardy, vice president and general manager, Comsearch.
"AuctionPlanner is easy to use and
its wealth of data is organized specifically to benefit spectrum
bidders. With AuctionPlanner, customers can easily and quickly
assess the spectrum encumbrances and make sound strategic decisions on
their bidding process. In addition, the new 700 MHz licensees will
rely on the timely transition of analog and digital TV stations to their
final digital channel allotments. The clear picture offered by
AuctionPlanner of the current operating TV stations will help 700 MHz
bidders evaluate whether any incumbency issues remain in a market, and aid
in monitoring the successful transition of TV stations out of the signal
band after the auction." |
|
CAMI isolation systems
permit other antennas to be mounted on "hot" AM
towers
LBA Technology, Inc. announces the
CAMI series of new-concept broadband medium-power isolators for AM towers.
CAMI isolation systems permit other antennas to be mounted on "hot" AM
towers.
CAMI systems are specifically
targeted to isolate single auxiliary broadcast coaxial cables for STL's,
FM translators, low power FM, and television translators. Unlike commonly
used isocouplers, one CAMI fits all of these applications. They also have
the advantage of passing AC or DC current to tower top amplifiers, and are
more resistant to weather and lightning.
Typical CAMI system specifications
are:
* Broadband transmission
frequency: DC - 2000 MHz * Broadband impedance: 50 ohms, VSWR
<1.2/1 * Insertion loss: 1.2 dB @ 100 MHz, 2.6 dB @ 960
MHz * Broadband power capability: 2.0 kW @ 100 MHz, 250 watts
@ 960 MHz * DC power passing * AM isolation frequency range:
500 - 2500 kHz * AM working voltage: 10 kV
peak * Lightweight, fast installation
With pending FCC approval of
translators for AM daytime stations, CAMI will provide an simple, cost
effective, way to mount the translator antenna on existing AM towers
without major changes to the transmitting system.
LBA Technology President Jerry
Brown commented "The CAMI isolator brings simplicity and reliability to
the installation of other services on AM towers. The uninterrupted,
stable, low loss signal path for these services is a real advantage. The
rugged environmentally hardened construction will pay real dividends in
reduced ongoing maintenance costs."
The CAMI isolator is priced competitively with other,
less capable isolators, and units can be shipped
immediately.
Contact John George, VP of Sales
at jgeorge@lbagroup.com or call (803) 951-7443, for pricing and
further information. |
|
New universal ring mount introduced by Site Pro
1 Site Pro 1 has announced the availability of another
universal installer-friendly product, a universal ring mount for mounting
accessories to monopoles.
The new universal ring mount
features: - A wider operating range to fit 12" to 45" OD
poles - A wider operating range eliminates the need to climb the
pole to verify the diameter saving time and money - 2 3/8" or
4-1/2" mounting pipes can be attached directly to the ring mount with
u-bolts - Features a 7" x 7" hole pattern as an industry standard
that is easily adaptable to various brands of
standoffs - Manufactured to the latest ANSI/TIA industry
standards
Additional information regarding
Site Pro 1's universal ring mount can be found online at www.sitepro1.com. It is fully stocked for same day shipping from any one of
the three Site Pro 1 distribution centers in New York, Atlanta and Los
Angeles. |
|
Andrew Corporation to retire LDF5 and LDF7 coaxial
workhorse cables at year's end If you had been in the wireless
design or construction industry for even a short length of time, LDF5 and
LDF7 rolled off the tongue as easily as their corresponding coaxial cable
sizes, 7/8" and 1-5/8".
The low density foam
coaxial cable became so popular within Andrew Corporation's HELIAX ®
products group during the past 30 years that many newcomers as well as
industry veterans thought that HELIAX ® was the technical term for all
corrugated copper cables. In the mid 1980s, a government RFQ specified Andrew's
1-5/8" LDF7, but allowed bidders to provide an approved equal, "providing
that it is heliax cable and meets all of the electrical specifications of
heliax coaxial cable."
However, on December 31, 2007 the
popular LDF5 and LDF7 cables will have an Auld Lang Syne production run
and the coaxial cable workhorses will no longer be
manufactured.
Building upon the market success
of its two most significant recent cable product introductions, Andrew is
streamlining its long-running and market-leading HELIAX® product portfolio
and featuring alternative products that offer higher value for customers.
With the revisions to its cable
product offerings, equivalently sized HELIAX Andrew Virtual Air™ (AVA™)
and HELIAX AL aluminum series cables will serve as direct replacements for
the LDF5 and LDF7 series coaxial cables.
"While the LDF series cable has
been the clear number one choice in the wireless industry for more than
three decades, technology improvements over the past three years have
enabled Andrew to introduce a new platform for copper and aluminum cables
that performs better than LDF," said Mike Guerin, vice president, Antenna
and Cable Products, Andrew Corporation. "With the successes of our
new aluminum cable product and our AVA series copper cable, Andrew
customers now can choose from two types of cables that provide even
greater technological benefits than they enjoyed with LDF5 and
LDF7."
HELIAX AVA series cables are the
lowest attenuation copper coaxial cables in the industry. Compared
to Andrew LDF series cables, AVA offers better performance in radio
frequency applications, with up to 10 percent lower attenuation in a
lighter weight, easier to install cable. AVA cable is ideal for customers
seeking to increase cell site performance versus other cable choices,
Guerin explained.
HELIAX AL series aluminum cables
enable construction of wireless base stations with the standard electrical
performance of an LDF series cable, but in a lighter, more flexible
cable. AL series is designed for customers seeking a high
performing, lighter-weight cable with reduced installation
costs.
"Building off the long-standing
tradition of quality and excellence that Andrew has delivered to the
communications industry for decades with its HELIAX coaxial cable
products, the AVA and AL series cables are establishing new performance
standards for the latest generation of wireless networks," Guerin
said.
With the exception of LDF5 and
LDF7 series cables, all other cable sizes in the LDF family will remain in
production and available from Andrew.
Andrew is implementing a 4.3 percent average price
increase for HELIAX cable in response to market conditions, particularly
the continued increases and volatility in raw material costs. The new
pricing
will be
effective October 1.
Talley Communications Corp., a leading
distributor of wireless communications infrastructure and mobile products,
announced this week they have entered into an agreement with Andrew, which
allows Talley to continue
to distribute Andrew's
LDF products.
"We are extremely proud of our long term relationship
with Andrew and now welcome the opportunity to continue to offer these LDF
series of cables to our customers," said Mark
Talley, President of
Talley Communications.
"The ability to continue distribution of the LDF
series cable is extremely important to providing Talley's customers with
unequalled customer support and effectively maintaining long
term customer stability,"
Talley said. |
New remote video cameras address industry's concern
for security and surveillance
The Hark VCR-100, VCR 80 and FFV 90 remote cameras offer significant
technology and application flexibility in locations with concerns for security and surveillance.
With remote control of pan, tilt, zoom
and optional motion sensing detection, the cameras are capable
of providing up to the minute imaging and observation for a number of
applications.
The overall benefit in reduced
insurance claims, and the increased safety through constant surveillance,
provides management the confidence required in today's work
environment.
Additional benefits of the remote cameras
include remote project management and work crew observation, reducing site
visits and controlling travel time and costs. In addition, a wireless
access point can be included to provide a wireless network at the site
location. Web services to provide convenient browser based access to the
video is also available for a monthly service fee.
Features and
Benefits: Full featured camera with pan, tilt
and zoom
Low Lux LCD camera provides clear video even in low light
conditions 180 degree horizontal pan, 50 Degree vertical tilt, 42x
Zoom Video and event history archive available Show customers and
prospects the progress of construction Manage sites remotely, reducing
travel and time Options: CDMA /
GPRS Wireless Modem Cable / DSL Modem Wireless Router Wireless
Motion Sensor Solar Power Optional For additional information
contact Hark Tower Systems at 3507 Iron Horse Drive, Building 200, Ladson,
SC 29456, 800-3674275 or visit them at www.harksystems.com |
|
Andrew introduces
its new
aluminum cable and
Positive Stop™
connector system Andrew has
introduced its Andrew HELIAX® aluminum cable and Positive Stop™
connectors-a complete solution for unmatched quality and longevity in
aluminum RF transmission line systems.
The complete Andrew solution is a systems approach,
combining premium HELIAX corrugated aluminum cable with Andrew's exclusive
patented Positive Stop™ spring-based, continuous-force
connectors.
According to Andrew, the combination of Andrew HELIAX
aluminum cable and Positive Stop connectors can stop costly degradation
before it starts, helping deliver performance and longevity that is
unmatched by any aluminum transmission line installation using smooth wall
cable or generic connectors.
Andrew says it
will guarantee its aluminum HELIAX cable for 10 years, as long as Positive
Stop connectors are used as part of the system.
|
|
CommScope
launches new version of its Extremeflex 7/8" 50-ohm transmission line
cable CommScope has introduced a new version of
its aluminum 50-ohm 7/8" Extremeflex® cable. The new FXL 780 cable is
smaller in diameter than its predecessor and designed to provide customers
with improved installation features such as greater flexibility and
standardized hardware accessories.
CommScope's years of aluminum cable experience have
enabled the company to produce a global 7/8" cable that offers
standardized hardware and accessories while maintaining its superior
electrical and mechanical performance as determined by published industry
specifications.
The FXL 780 cable supplements CommScope's already
extensive line of Extremeflex cables that offer lighter tower loading,
greater flexibility and lower life cycle cost by reducing on- going
maintenance.
"FXL 780 is currently being installed globally with
select major carriers on a trial basis," said Senior Vice President Larry
Nelson, CommScope's Chief Technical Officer for Wireless
Engineering.
"Feedback has been extremely positive with regard to
electrical performance and mechanical handling. We envision FXL 780 as the
next generation 7/8" cable and expect FXL 780 to gain worldwide acceptance
as a cost-effective alternative to traditional 7/8" copper-based
products," Nelson said.
CyberLock brings an audit trail and key
control
Tough,
intelligent, and built with stainless steel components, the unique design
of these electronic padlocks allows them to perform extremely well
in the harshest outdoor environments.
The system
consists of the CyberLock electronic padlock that cannot be compromised by
any conventional lock-picking methods, and the CyberKey that cannot be
duplicated. As with all CyberLocks, you can restrict access for
authorized users to selected locks on specific days, and only during
certain times on those days. Each time the CyberKey opens a padlock, a
record of the event is stored in both the padlock and key, providing a
comprehensive audit trail of activity.
The CyberLock
family of electronic padlocks is constantly growing and includes a line of
standard solid-body brass padlocks with stainless steel components.
Two new additions are the Hockey Puck and Bar Bell. The Hockey Puck,
with a stainless steel body and anti-drilling features built into its
core, is highly resistant to violent force. When in the closed
position, its buried shackle prevents attacks from bolt-cutters. The
Bar Bell padlock has a stainless steel core and locking post.
Environmentally sealed with "O"rings to prevent water and dirt from
reaching its inner core, it is ideal for applications such as sealing
underground utility vaults and marine cargo containers.
For more
information about CyberLock products, contact Videx by phone at (541)
758-0521, by fax at (541) 752-5285, by email at sales@videx.com, or
visit the web site at www.videx.com.
PIPEx-P tower reinforcement proves to be
great off the shelf product for additional tower capacity
Structural Components, LLC recently introduced a pre-engineered,
off the shelf structural reinforcement designed to increase the load
carrying capacity of any round leg lattice tower.
Unique to the PIPEx-P
reinforcement system are the adjustable butterfly attachment plates that
connect to the tower legs.
These attachment plates can be
located anywhere between panels to clear mounts and other
obstructions. New sub-horizontal members can be installed with ease
for small overstresses of up to 20% in the legs. Lattice bracing and
external pipes can be attached to the bolt-on brackets at any time (should
further reinforcing be required) becoming the main support for the
tower(exoskeleton).
This reinforcement more
than triples the load carrying capacity of a Rohn 25G or 45G allowing for
up to three three full platforms. For additional information,
contact:
Structural Components,
LLC, 1617 Pearl Street, Suite 200, Boulder, CO 80302-5410. Tel:
866-386-7622.
www.structuralcomponents.net
Step-Over rooftop product ideal
for protection Site Pro 1, Inc. has introduced its new
aluminum Step-Overs for rooftop applications. The Step-Over provides a
permanent, maintenance-free step over solution which prevents damage caused by
foot traffic to cables, cable trays, lines and ducts. Site Pro 1's
Step-Over features:
-All aluminum construction keeps the product lightweight for use in
elevators. - No assembly required like existing "bridge kits" - The
Heliarc welded, heavy duty, aluminum frames are rust and maintenance
free. -Non-skid treads on platform are self-cleaning. -Load rating
is 1,200 lbs
Additional
information regarding the company's Step-Over can be found online at
www.sitepro1.com. The
Step-Over is stocked in depth for same day shipping from any one of the
three Site Pro 1 distribution centers in New York, Atlanta and now Los
Angeles.
Lighter, more universal boom gate is introduced
The new Connect-It
Wireless Components' 13' boom gate is now a lighter more
universal version of the past gate, according to company President Jim
Schultz.
Schultz said the new universal foot set allows the boom gate to
attach to guyed or tapered towers with up to an 8" round leg or a 6" angle
leg. A larger foot set is also available for legs up to 12 ½" OD.
The face of the mount easily pivots to adjust antenna azimuths and
accepts up to five antennas. Schultz says one of the best features of the
frame is that the entire mount assembles in minutes.
The new boom gates are strong, designed with the tropical weather
of Florida in mind and are built to withstand winds up to 150MPH. They are
engineered to the latest industry standards (FL Building Code & TIA/
EIA- 222- G).
Engineering cut sheets are gladly supplied upon
request or just look on their web site
for the required engineering data.
The boom gate comes complete with universal foot set, 3' standoff,
face & support angles, 2 stiff arms, and 4 antenna masts. There are no
extra parts to purchase.
Connect-It Wireless' stringent designs have proven to withstand
hurricane force winds throughout the country. They have withstood five
Category 1, five Category 2, four Category 3, and one Category 4
hurricanes without a single reported failure, Schultz says.
"We have achieved this success rate with an engineering philosophy
that accounts for a nearly infinite mount and antenna configuration," said
Schultz.
The veteran manufacturer explained that their published load limits
are conservative and generic in nature.
"These limits allow virtually any shaped antenna to be mounted at
any altitude and at any azimuth. To accomplish this goal safely, we assume
worst-case conditions in our analyses:
1. The antenna weight will equal the Maximum Combined Load
Weight; 2. The antenna wind drag will equal the Maximum Combined Load
Force; 3. The antenna area will equal the Maximum Combined Load
Area; 4. The antenna area will be the largest cross-sectional area of
the antenna; 5. The mount's effective projected area is the largest
cross-sectional area of the mount; 6. The mount's effective projected area
normal to the azimuth is the cross-sectional area of the mount normal to
the largest cross-section area of the mount."
EPAT and EPAN to assist
engineers
"Our load ratings are determined in accordance with
TIA-EIA-222-G, the Florida Building Code 2004, and A.S.C.E. 7-02. Revision G of
the TIA-EIA-222 code was substantial and we are in the process of updated
our drawing database so that all of our drawings will provide the
mount's total effective projected area (EPAT) and the mount's effective
projected area normal to the azimuth (EPAN). We will also provide load limits
at two wind speeds, 140 MPH and 150 MPH," Schultz said.
"Of course, we can increase these limits for site-specific installations," he
explained.
"To simplify access
to this information we plan to provide the same information for
each mount on our web
page in the coming months. We believe this will make the engineer's
life a little easier to spec mounts for their specific needs," he
said.
Ex-Press™ coax mounting band allows
for easy installs on
poles
Andrew's new Ex-Press™
Expansion/Compression Coax Mounting Band has been one of the industry's
most sought after products for installing multiple runs of coaxial cable
on the inside or outside of round or polygon structures up to 60" in
diameter.
Their Ex-Press™ Band is
the only coax mounting band in the industry featuring both expansion and
compression capabilities. The Express™ Band can be mounted on the
inside of water tank access tubes with 36" to 60" inside diameters or the
outside of round and polygon monopoles with 10" to 60" outside
diameters.
Long noted for their
innovative field-tested products, Andrew's mounting bands are
available from: Primus Electronics , Talley Communications and TESSCO.
Safety
and structural integrity highlight two monopole
products from B&C Two new monopole-related products were
introduced to the industry by B&C Contracting at the 2006 PCIA show in
Nashville, drawing interest from contractors and carriers
alike.
To help protect the monopole owners' assets,
B&C has developed their POLE-CAM©, designed exclusively for viewing
and recording the inside of monopoles.
The system enables contractors to determine the
location of all coaxial lines as well as combustible materials such as
bird nests that can be ignited when contractors are welding upon the
structures.
"Although it is important to have a fire
prevention safety plan in place whenever you are welding on a monopole,
that's a reactive measure," said Doug Coberley, President of B&C
Contracting.
"The POLE-CAM© system can prevent fires by
clearly identifying where there are areas within the monopole that should
be addressed whenever you are going to weld on the pole," he
said.
Coberley points out that the system is an
excellent tool for ensuring the safety of transmission lines and other
assets for any tower modification whether it is a welded, bolted or a
porthole installation.
Numerous fires are reported every year within
monopoles. In most instances the highly flammable transmission lines will
cause severe damage to the pole causing expensive replacement costs and
carrier interruptions.
"POLE-CAM©" comes equipped with a 2"
diameter wide angle lens with 24
LED lights built into the camera lens. It has 500'
of coax cable and a monitor with integrated DVD as
well as a DVD Recorder.
The
"POLE-CAM©" system is self contained in a roll-around enclosure. To
identify how easily the inside of the pole can be investigated, a
video is available at www.bandccontracting.com
Porthole rim easily provides
compliant entry for new tenants
In order to provide a complete joint penetration weld, contractors must use a backing material or
weld from both sides of the monopole.
When installing portholes on the top of most monopoles it is impossible to weld
on the inside. Coberley said his entry port allows for a CJP at
any level from the outside of the structure.
"Although you can weld on the inside of a
bottom port in most instances, this product will not require a confined
space entry permit and all the safety requirements that are necessary," he
said.
For additional information on both products you can
visit B&C at www.bandccontrating.com
or
contact Coberley at doug@bandccontracting.com

|
|
|
